SFS10482R5C

Technical Details

• Series:SFS (10W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):76V
• Voltage - Output 1:2.5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):3A
• Power (Watts):7.5 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:86%
• Mounting Type:Through Hole
• Package / Case:20-DIP Module, 17 Leads
• Size / Dimension:1.52" L x 1.07" W x 0.20" H (38.7mm x 27.2mm x 5.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
