ERM01CC18

Technical Details

• Series:ERM (20W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):667mA, 667mA
• Power (Watts):20 W

• Voltage - Isolation:3 kV
• Applications:Railway
• Features:Remote On/Off, OCP, OTP, OVP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:86%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:2.00" L x 1.00" W x 0.43" H (50.8mm x 25.4mm x 11.0mm)
• Supplier Device Package:6-DIP
• Control Features:-
• Approval Agency:-
• Standard Number:-
