TMR 9-4822WI

Technical Details

• Series:TMR 9WI (9W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):375mA, 375mA
• Power (Watts):9 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:8-SIP Module, 6 Leads
• Size / Dimension:0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB, cURus
• Standard Number:-
