SUCW101215BP

Technical Details

• Series:SUCW (10W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):350mA, 350mA
• Power (Watts):11 W

• Voltage - Isolation:500 V
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:86%
• Mounting Type:Surface Mount
• Package / Case:7-SMD Module
• Size / Dimension:1.58" L x 0.85" W x 0.28" H (40.2mm x 21.5mm x 7.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
