TON 15-2410WISM

Technical Details

• Series:TON 15WI (15W)
• Package:Tray
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):4A
• Power (Watts):13 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OVP, SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:85%
• Mounting Type:Surface Mount
• Package / Case:6-SMD Module
• Size / Dimension:1.10" L x 0.94" W x 0.33" H (27.9mm x 23.9mm x 8.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
