THD 15-4821WIN
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 15W
- CategoryDC DC Converters
- Datasheet THD 15-4821WIN Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$51.222
- 10$51.222
Quote It
Technical Details
- Series:THD 15WIN (15W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):18V
- Voltage - Input (Max):75V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):1.5A, 1.5A
- Power (Watts):15 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OVP, SCP
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:86%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 8 Leads
- Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
