TEN 25-1213

Technical Details

• Series:TEN 25 (30W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):2A
• Power (Watts):30 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OVP, SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:7-DIP Module, 6 Leads
• Size / Dimension:2.00" L x 1.60" W x 0.37" H (50.8mm x 40.6mm x 9.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
