ECLB60W-24S33N

Technical Details

• Series:ECLB60W (60W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):15A
• Power (Watts):50 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:90.5%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:2.05" L x 1.20" W x 0.40" H (52.0mm x 30.5mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:CE
• Standard Number:-
