PTB48580BAH

Technical Details

• Series:PTB48580
• Package:Tray
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.25A, 1.25A
• Power (Watts):30 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module
• Size / Dimension:2.00" L x 1.60" W x 0.41" H (50.8mm x 40.6mm x 10.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
