PKM4717BNHPISP
Flex Power Modules
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 10.8V 756W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$72.128
Quote It
Technical Details
- Series:PKM4000NH (756W)
- Package:Tray
- Part Status:Active
- Type:Intermediate Bus Converter
- Number of Outputs:1
- Voltage - Input (Min):40V
- Voltage - Input (Max):60V
- Voltage - Output 1:10.8V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):70A
- Power (Watts):756 W
- Voltage - Isolation:2.25 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off
- Operating Temperature:-40°C ~ 125°C (With Derating)
- Efficiency:96.9%
- Mounting Type:Through Hole
- Package / Case:Quarter Brick
- Size / Dimension:2.28" L x 1.45" W x 0.45" H (57.9mm x 36.8mm x 11.4mm)
- Supplier Device Package:Quarter Brick
- Control Features:Enable, Active Low
- Approval Agency:CB, CSA, IEC, TUV, UL
- Standard Number:62368-1
