40IMX7-24-24-8G

Technical Details

• Series:Melcher IMX7 (7W)
• Package:Bulk
• Part Status:Active
• Type:Isolated Module, Conformal Coated
• Number of Outputs:2
• Voltage - Input (Min):16.8V
• Voltage - Input (Max):75V
• Voltage - Output 1:24V
• Voltage - Output 2:24V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):150mA, 150mA
• Power (Watts):7.2 W

• Voltage - Isolation:2.1 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:84%
• Mounting Type:Through Hole
• Package / Case:14-DIP Module, 9 Leads
• Size / Dimension:2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.4mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
