PQA50-D48-S12-D
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 50W
- CategoryDC DC Converters
- Datasheet PQA50-D48-S12-D Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$75.2
- 5$74.612
- 19$74.02526
- 38$71.675
- 57$68.15
- 114$63.45
Quote It
Technical Details
- Series:PQA50-D (50W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):36V
- Voltage - Input (Max):75V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):4.167A
- Power (Watts):50 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, OVP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C
- Efficiency:93%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 11.8mm)
- Supplier Device Package:-
- Control Features:Enable, Active High
- Approval Agency:CB Scheme, IEC
- Standard Number:60950-1
