DAQ0150V2PBC

Technical Details

• Series:DAQ (600W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50A
• Power (Watts):600 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OTP, OVP, SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:96%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.30" L x 1.45" W x 0.52" H (58.4mm x 36.8mm x 13.2mm)
• Supplier Device Package:Quarter Brick
• Control Features:-
• Approval Agency:-
• Standard Number:-
