PKM7115APIP
Flex Power Modules- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 100W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$84.70896
Quote It
Technical Details
- Series:PKM 7000A (150W)
- Package:Tray
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):66V
- Voltage - Input (Max):160V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):6.67A
- Power (Watts):100 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial), Railway
- Features:Adjustable Output, Remote On/Off, Remote Sense
- Operating Temperature:-40°C ~ 115°C (With Derating)
- Efficiency:90%
- Mounting Type:Through Hole
- Package / Case:Quarter Brick
- Size / Dimension:2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm)
- Supplier Device Package:Quarter Brick
- Control Features:Enable, Active High
- Approval Agency:CB, CSA, EN, IEC, TUV, UL
- Standard Number:50155; 62368-1
