DRQ-8/100-L48PBAS-C

Technical Details

• Series:DRQ-8/100-L48NBxxxx-C (800W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):60V
• Voltage - Output 1:8V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):100A
• Power (Watts):800 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Baseplate, Load Sharing, Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:95.8%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.30" L x 1.45" W x 0.57" H (58.4mm x 36.8mm x 14.5mm)
• Supplier Device Package:Quarter Brick
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
