CQS24150-8-N

Technical Details

• Series:CQS (140W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):20V
• Voltage - Input (Max):33V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):8A
• Power (Watts):120 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:92%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module
• Size / Dimension:2.28" L x 1.45" W x 0.33" H (57.9mm x 36.8mm x 8.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
