110IMX35D05D12-8G

Technical Details

• Series:Melcher IMX35 (35W)
• Package:Bulk
• Part Status:Active
• Type:Isolated Module, Conformal Coated
• Number of Outputs:4
• Voltage - Input (Min):60V
• Voltage - Input (Max):150V
• Voltage - Output 1:5V
• Voltage - Output 2:12V
• Voltage - Output 3:12V
• Voltage - Output 4:-
• Current - Output (Max):1.4A, 700mA, 700mA
• Power (Watts):35 W

• Voltage - Isolation:2.5 kV
• Applications:ITE (Commercial), Railway
• Features:OCP, OTP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:19-DIP Module, 17 Leads
• Size / Dimension:3.00" L x 2.50" W x 0.41" H (76.2mm x 63.5mm x 10.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
