0RQB-D0W12LG

Technical Details

• Series:0RQB-D0W12L
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):50V
• Voltage - Input (Max):136V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):16.7A
• Power (Watts):200 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 95°C
• Efficiency:93%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.45" L x 1.45" W x 0.59" H (62.2mm x 36.8mm x 15.0mm)
• Supplier Device Package:Quarter Brick
• Control Features:Enable, Active Low
• Approval Agency:-
• Standard Number:-
