RZ-2415S/P-R

Technical Details

• Series:ECONOLINE RZ (0.5W)
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):33mA
• Power (Watts):500 mW

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 70°C
• Efficiency:62%
• Mounting Type:Surface Mount
• Package / Case:10-SMD Module, 6 Leads
• Size / Dimension:0.60" L x 0.32" W x 0.29" H (15.2mm x 8.2mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
