PT78NR115H

Technical Details

• Series:PT78NR100
• Package:Tray
• Part Status:Obsolete
• Type:Non-Isolated PoL Module
• Number of Outputs:1
• Voltage - Input (Min):7V
• Voltage - Input (Max):15V
• Voltage - Output 1:-15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):300mA
• Power (Watts):-

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:OTP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:75%
• Mounting Type:Through Hole, Right Angle
• Package / Case:3-SIP Module
• Size / Dimension:0.94" L x 0.90" W x 0.31" H (23.9mm x 22.9mm x 7.9mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
