PTK10-Q48-D12

Technical Details

• Series:PTK10 (10W)
• Package:Box
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):20V
• Voltage - Input (Max):72V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):450mA, 450mA
• Power (Watts):10 W

• Voltage - Isolation:500 V
• Applications:ITE (Commercial)
• Features:OCP, OVP
• Operating Temperature:-20°C ~ 71°C
• Efficiency:83%
• Mounting Type:Through Hole
• Package / Case:5-DIP Module
• Size / Dimension:2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
