NDTS1203C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 3.3V 3W
- CategoryDC DC Converters
- Datasheet NDTS1203C Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$16.98
- 5$16.9
- 10$16.78
- 25$16.58
Quote It
Technical Details
- Series:NDTS (3W)
- Package:Tube
- Part Status:Obsolete
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:3.3V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):909mA
- Power (Watts):3 W
- Voltage - Isolation:1 kV
- Applications:ITE (Commercial)
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Efficiency:71%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module (600 mil, 8 Leads)
- Size / Dimension:1.27" L x 0.58" W x 0.27" H (32.3mm x 14.7mm x 6.9mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
