NMH0524DC

Technical Details

• Series:NMH (2W)
• Package:Tube
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:24V
• Voltage - Output 2:-24V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):42mA, 42mA
• Power (Watts):2 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:84%
• Mounting Type:Through Hole
• Package / Case:14-DIP Module, 6 Leads
• Size / Dimension:0.77" L x 0.39" W x 0.30" H (19.6mm x 9.9mm x 7.6mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
