VWQBS2-Q24-S12-SIP

Technical Details

• Series:VWQBS2-SIP (2W)
• Package:Tube
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):167mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:82%
• Mounting Type:Through Hole
• Package / Case:9-SIP Module, 7 Leads
• Size / Dimension:1.02" L x 0.37" W x 0.49" H (26.0mm x 9.5mm x 12.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
