YNV05T16-0

Technical Details

• Series:Y (58W)
• Package:Bulk
• Part Status:Obsolete
• Type:Non-Isolated PoL Module
• Number of Outputs:1
• Voltage - Input (Min):3V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:0.7525 ~ 3.63V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):16A
• Power (Watts):58 W

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OTP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:93.5%
• Mounting Type:Through Hole
• Package / Case:10-SIP Module
• Size / Dimension:2.00" L x 0.28" W x 0.54" H (50.8mm x 7.1mm x 13.6mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
