VESD1-S15-D9-SIP
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-9V 1W
- CategoryDC DC Converters
- Datasheet VESD1-S15-D9-SIP Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:VESD1-SIP (1W)
- Package:Bulk
- Part Status:Obsolete
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):13.5V
- Voltage - Input (Max):16.5V
- Voltage - Output 1:9V
- Voltage - Output 2:-9V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):56mA, 56mA
- Power (Watts):1 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 85°C
- Efficiency:75%
- Mounting Type:Through Hole
- Package / Case:7-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.24" W x 0.39" H (19.6mm x 6.1mm x 9.9mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
