UCE-5/20-D48NB-C

Technical Details

• Series:UCE
• Package:Tube
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):20A
• Power (Watts):100 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:92.5%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 1/8 Brick
• Size / Dimension:2.30" L x 0.90" W x 0.37" H (58.4mm x 22.9mm x 9.4mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
