UHE-3.3/7500-D48-C

Technical Details

• Series:UHE (30W)
• Package:Tube
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):7.5A
• Power (Watts):25 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OTP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:88.7%
• Mounting Type:Through Hole
• Package / Case:9-DIP Module, 6 Leads
• Size / Dimension:2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
