ULQ-12/8-D24N-C

Technical Details

• Series:ULQ
• Package:Tray
• Part Status:Obsolete
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):36V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):8A
• Power (Watts):96 W

• Voltage - Isolation:2 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:90.5%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 1/4 Brick
• Size / Dimension:2.22" L x 1.35" W x 0.38" H (56.4mm x 34.3mm x 9.53mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:-
• Standard Number:-
