SG-310SDF 4.9152MC

Technical Details

• Series:SG-310SDF
• Package:Strip
• Part Status:Not For New Designs
• Base Resonator:Crystal
• Type:XO (Standard)
• Frequency:4.9152 MHz
• Function:Standby (Power Down)
• Output:CMOS
• Voltage - Supply:2.5V
• Frequency Stability:±100ppm

• Absolute Pull Range (APR):-
• Operating Temperature:-20°C ~ 70°C
• Spread Spectrum Bandwidth:-
• Current - Supply (Max):1.5mA
• Ratings:-
• Mounting Type:Surface Mount
• Package / Case:4-SMD, No Lead
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
• Height - Seated (Max):0.047" (1.20mm)
