0559171630
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 16POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0559171630 Datasheet
-
ECAD Model
- Share
In Stock: 4,728
Can ship immediately
Pricing:
- 1$1.54
- 10$1.34991
- 100$1.16486
- 600$0.95309
- 1,200$0.84719
- 5,400$0.74129
- 10,200$0.70422
Quote It
Technical Details
- Series:MicroClasp 55917
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:16
- Number of Rows:2
- Row Spacing - Mating:0.197" (5.00mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:0.150" (3.81mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:0.366" (9.30mm)
- Insulation Height:0.384" (9.75mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
