0462070110
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 10POS 4.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0462070110 Datasheet
-
ECAD Model
- Share
In Stock: 722
Can ship immediately
Pricing:
- 1$2.73
- 10$2.6208
- 25$2.402
- 50$2.2928
- 100$2.1836
- 250$1.91064
- 500$1.85606
- 1,000$1.58311
- 2,500$1.47393
Quote It
Technical Details
- Series:Mini-Fit Jr 46207
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.165" (4.20mm)
- Number of Positions:10
- Number of Rows:2
- Row Spacing - Mating:0.165" (4.20mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:0.176" (4.46mm)
- Overall Contact Length:-
- Insulation Height:0.535" (13.60mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:100.0µin (2.54µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
- Features:Board Guide
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
