MX34036UF2
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 36POS 2.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX34036UF2 Datasheet
-
ECAD Model
- Share
In Stock: 1,224
Can ship immediately
Pricing:
- 1$2.9
- 10$2.77917
- 25$2.54757
- 50$2.43177
- 100$2.31597
- 250$2.0265
- 500$1.96858
- 1,000$1.67908
- 2,500$1.56328
Quote It
Technical Details
- Series:MX34
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.087" (2.20mm)
- Number of Positions:36
- Number of Rows:2
- Row Spacing - Mating:0.118" (3.00mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:0.303" (7.70mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:-
- Insulation Height:0.925" (23.50mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
- Features:Mounting Flange
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):3A
- Voltage Rating:-
