MX23A34NF6
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 34POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX23A34NF6 Datasheet
-
ECAD Model
- Share
In Stock: 897
Can ship immediately
Pricing:
- 1$9.38
- 10$8.97411
- 100$7.54641
- 500$6.32267
- 1,000$5.58842
Quote It
Technical Details
- Series:MX23A
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:34
- Number of Rows:2
- Row Spacing - Mating:0.173" (4.40mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:-
- Insulation Height:0.720" (18.30mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:Waterproof
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):3A
- Voltage Rating:-
