MX23A40NF1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 40POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX23A40NF1 Datasheet
-
ECAD Model
- Share
In Stock: 279
Can ship immediately
Pricing:
- 1$21.08
- 10$19.57804
- 25$17.57024
- 50$17.06803
- 100$15.06003
- 250$14.05603
- 500$13.75483
Quote It
Technical Details
- Series:MX23A
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:40
- Number of Rows:3
- Row Spacing - Mating:0.173" (4.40mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:-
- Insulation Height:0.720" (18.30mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:Waterproof
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):3A
- Voltage Rating:-
