IL-G-8P-S3T2-SA
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 8POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet IL-G-8P-S3T2-SA Datasheet
-
ECAD Model
- Share
In Stock: 2,392
Can ship immediately
Pricing:
- 1$0.48
- 10$0.45
- 100$0.345
- 500$0.3
- 1,000$0.2475
- 5,000$0.2175
- 10,000$0.2025
Quote It
Technical Details
- Series:IL-G
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:8
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.157" (4.00mm)
- Contact Length - Post:0.138" (3.50mm)
- Overall Contact Length:0.378" (9.60mm)
- Insulation Height:0.280" (7.10mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Brown
- Current Rating (Amps):3A per Contact
- Voltage Rating:-
