0559350530
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 5POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0559350530 Datasheet
-
ECAD Model
- Share
In Stock: 7,235
Can ship immediately
Pricing:
- 1$0.51
- 10$0.47892
- 100$0.36728
- 900$0.28745
- 1,800$0.25551
- 5,400$0.23156
- 10,800$0.21559
Quote It
Technical Details
- Series:MicroClasp 55935
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:5
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:0.144" (3.66mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:-
- Insulation Height:0.264" (6.70mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
