0557550619
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 6POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0557550619 Datasheet
-
ECAD Model
- Share
In Stock: 16,959
Can ship immediately
Pricing:
- 1$0.56
- 10$0.52436
- 100$0.40228
- 780$0.31486
- 1,560$0.27988
- 5,460$0.25364
- 10,140$0.23615
Quote It
Technical Details
- Series:MicroTPA 55755
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:6
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:0.144" (3.66mm)
- Contact Length - Post:0.130" (3.30mm)
- Overall Contact Length:0.437" (11.10mm)
- Insulation Height:0.352" (8.94mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Features:Board Guide
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
