0026602050
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 5POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0026602050 Datasheet
-
ECAD Model
- Share
In Stock: 10,253
Can ship immediately
Pricing:
- 1$0.6
- 10$0.558
- 100$0.4278
- 500$0.372
- 1,000$0.3069
- 5,000$0.2697
- 10,000$0.2511
Quote It
Technical Details
- Series:KK396, 41771
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:5
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.450" (11.43mm)
- Contact Length - Post:0.140" (3.56mm)
- Overall Contact Length:0.720" (18.29mm)
- Insulation Height:0.130" (3.30mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:60.0µin (1.52µm)
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polyester, Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
