0874371273
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 12POS 1.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0874371273 Datasheet
-
ECAD Model
- Share
In Stock: 3,876
Can ship immediately
Pricing:
- 1$1.14
- 900$1.14
- 1,800$0.97235
- 2,700$0.93882
- 6,300$0.89188
- 9,000$0.87176
Quote It
Technical Details
- Series:Pico-SPOX 87437
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.059" (1.50mm)
- Number of Positions:12
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.106" (2.70mm)
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.199" (5.05mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:100.0µin (2.54µm)
- Contact Finish - Post:Tin
- Contact Material:Brass Alloy
- Insulation Material:Polyamide (PA), Nylon, Glass Filled
- Features:Pick and Place
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Beige
- Current Rating (Amps):-
- Voltage Rating:-
