N3428-6203RB

3M
In Stock: 337

Can ship immediately

Pricing:
  • 1$3.55
  • 10$3.40779
  • 100$2.84
  • 500$2.414
  • 1,000$2.059
  • 5,000$1.846

Quote It

Technical Details

  • Series:3000
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:20
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Lock/Eject Hooks, Short
  • Contact Length - Mating:0.240" (6.10mm)



  • Contact Length - Post:0.155" (3.94mm)
  • Overall Contact Length:0.695" (17.65mm)
  • Insulation Height:0.680" (17.27mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:Keying Slot, Mounting Flange
  • Operating Temperature:-55°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):1.75A
  • Voltage Rating:-
