0313874018
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 80POS 2.54MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0313874018 Datasheet
-
ECAD Model
- Share
In Stock: 331
Can ship immediately
Pricing:
- 1$14.2
- 10$12.91333
- 100$10.97638
- 500$9.36217
- 1,000$8.58737
Quote It
Technical Details
- Series:MX123 31387
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.100" (2.54mm)
- Number of Positions:80
- Number of Rows:4
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:-
- Contact Length - Post:0.256" (6.50mm)
- Overall Contact Length:-
- Insulation Height:0.848" (21.54mm)
- Contact Shape:Square
- Contact Finish - Mating:Silver
- Contact Finish Thickness - Mating:74.8µin (1.90µm)
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):-
- Voltage Rating:-
