0026202031

Woodhead - Molex
In Stock: 6,974

Can ship immediately

Pricing:
  • 1$0.58
  • 10$0.542
  • 100$0.4154
  • 500$0.3612
  • 1,000$0.29799
  • 5,000$0.26187
  • 10,000$0.24381

Quote It

Technical Details

  • Series:KK396, 3192
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.156" (3.96mm)
  • Number of Positions:3
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.450" (11.43mm)



  • Contact Length - Post:0.175" (4.45mm)
  • Overall Contact Length:0.750" (19.05mm)
  • Insulation Height:0.125" (3.18mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA), Nylon
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-2
  • Insulation Color:Natural
  • Current Rating (Amps):-
  • Voltage Rating:-
