In Stock: 7,087

Can ship immediately

Pricing:
  • 1$0.68
  • 10$0.6357
  • 100$0.48764
  • 500$0.42403
  • 1,000$0.34983
  • 5,000$0.30742
  • 10,000$0.28622

Quote It

Technical Details

  • Series:CT
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:8
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Kinked Pin, Solder
  • Fastening Type:Detent Lock
  • Contact Length - Mating:0.165" (4.20mm)



  • Contact Length - Post:0.126" (3.20mm)
  • Overall Contact Length:0.358" (9.09mm)
  • Insulation Height:0.268" (6.80mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA66), Nylon 6/6
  • Features:Board Guide
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Natural
  • Current Rating (Amps):Varies by Wire Gauge
  • Voltage Rating:125VAC

Related Products


3-1376382-4

CONN HEADER VERT 2POS 5MM

3-1376382-4 Datasheet
  • 1: $0.68000
  • 10: $0.63300
  • 100: $0.48540

7-1747072-4

CONN HEADER VERT 4POS 2.5MM

7-1747072-4 Datasheet
  • 1: $1.40000
  • 450: $1.06011
  • 900: $0.93966

1-440054-1

CONN HEADER VERT 11POS 2MM

1-440054-1 Datasheet
  • 1: $0.69000
  • 10: $0.60493
  • 100: $0.52175

2-292132-4

CONN HEADER VERT 4POS 2MM

2-292132-4 Datasheet
  • 1: $0.69000
  • 10: $0.64821
  • 100: $0.50652

54025-06-0100-01

WIRE-TO BOARD WAFER, 2.5MM, 6 CO

  • 1: $0.70000

0026192031

CONN HEADER VERT 3POS 3.96MM

0026192031 Datasheet
  • 1: $0.70000
  • 10: $0.65300
  • 100: $0.50050

0010977085

CONN HEADER VERT 8POS 2.54MM

0010977085 Datasheet
  • 1: $0.70000
  • 10: $0.66000
  • 100: $0.50580

4282-1-0200-08-SP

CONN HEADER R/A 8POS DUAL 94V-0

  • 1: $0.71000

IL-G-8P-S3L2-SA

CONN HEADER R/A 8POS 2.5MM

IL-G-8P-S3L2-SA Datasheet
  • 1: $0.70000
  • 10: $0.65932
  • 100: $0.51403

0022035155
