0535170410
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 4POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0535170410 Datasheet
-
ECAD Model
- Share
In Stock: 5,545
Can ship immediately
Pricing:
- 1$0.76
- 10$0.6688
- 100$0.57699
- 900$0.45894
- 1,800$0.39338
- 5,400$0.36715
- 10,800$0.34879
Quote It
Technical Details
- Series:Mini-Lock 53517
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:4
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:0.157" (4.00mm)
- Contact Length - Post:0.138" (3.50mm)
- Overall Contact Length:0.610" (15.50mm)
- Insulation Height:0.689" (17.50mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Phosphor Bronze
- Insulation Material:Polyamide (PA), Nylon
- Features:Board Guide, Glow Wire Compliant
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
