In Stock: 10,001

Can ship immediately

Pricing:
  • 1$1.02
  • 10$0.90864
  • 100$0.79242
  • 500$0.66034
  • 1,000$0.59431
  • 5,000$0.52828
  • 10,000$0.50516

Quote It

Technical Details

  • Series:High Performance Interconnect (HPI)
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:16
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 3 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Press-Fit, Solder
  • Fastening Type:-
  • Contact Length - Mating:0.138" (3.50mm)



  • Contact Length - Post:0.134" (3.40mm)
  • Overall Contact Length:-
  • Insulation Height:0.195" (4.95mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:80.0µin (2.03µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Thermoplastic
  • Features:-
  • Operating Temperature:-25°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Natural
  • Current Rating (Amps):3A
  • Voltage Rating:250V
