3-644611-5
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 5POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 3-644611-5 Datasheet
-
ECAD Model
- Share
In Stock: 2,630
Can ship immediately
Pricing:
- 1$1.69
- 10$1.5336
- 100$1.31463
- 500$1.09552
- 1,000$0.93902
- 5,000$0.8326
- 10,000$0.81381
Quote It
Technical Details
- Series:MTA-156
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:5
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.450" (11.43mm)
- Contact Length - Post:0.125" (3.18mm)
- Overall Contact Length:0.700" (17.78mm)
- Insulation Height:0.545" (13.84mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:150.0µin (3.81µm)
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic, Glass Filled
- Features:-
- Operating Temperature:-55°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:600VAC
