0346910162
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 16POS 2.54MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0346910162 Datasheet
-
ECAD Model
- Share
In Stock: 1,905
Can ship immediately
Pricing:
- 1$2.27
- 10$2.06832
- 100$1.79518
- 616$1.52201
- 1,232$1.32689
- 5,544$1.1942
Quote It
Technical Details
- Series:Stac64 34691
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.100" (2.54mm)
- Number of Positions:16
- Number of Rows:2
- Row Spacing - Mating:0.100" (2.54mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.119" (3.02mm)
- Overall Contact Length:-
- Insulation Height:0.868" (22.05mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Cartridge Brass
- Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Brown
- Current Rating (Amps):-
- Voltage Rating:-
