280612-2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 8POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 280612-2 Datasheet
-
ECAD Model
- Share
In Stock: 845
Can ship immediately
Pricing:
- 1$5.46
- 10$5.24491
- 100$4.3706
- 500$3.71502
- 1,000$3.16869
Quote It
Technical Details
- Series:AMPMODU Mod I
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:8
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 2 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:0.394" (10.00mm)
- Contact Length - Post:0.130" (3.30mm)
- Overall Contact Length:0.642" (16.30mm)
- Insulation Height:0.913" (23.20mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:15.0µin (0.38µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polycarbonate, Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Green
- Current Rating (Amps):-
- Voltage Rating:-
