0026482240
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 24POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0026482240 Datasheet
-
ECAD Model
- Share
In Stock: 1,311
Can ship immediately
Pricing:
- 1$8.42
- 10$8.05569
- 100$6.77385
- 500$5.67538
- 1,000$5.0163
Quote It
Technical Details
- Series:KK396, 41661
- Package:Bulk
- Part Status:Active
- Connector Type:Header, Breakaway
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:24
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.590" (14.99mm)
- Contact Length - Post:0.172" (4.37mm)
- Overall Contact Length:0.890" (22.61mm)
- Insulation Height:0.128" (3.25mm)
- Contact Shape:Square
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:20.0µin (0.51µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyester, Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
